Misonics EVS 600 Heavy Industrial Ultrasonic Cleaner

The production tank · heavy industrial · AS3100 certified

600 LSS316 3 mm insulated
10,500 W7 generators · 25 kHz
1200×800tank mm
Automateddouble-skinned lid
PLC/HMI+ remote access
The EVS 600 replaces the MSX 500. The MSX 500 sat at the top of a workshop range and was being asked to do industrial work. The EVS 600 is built for it from the start — heavier tank construction, an elevator platform so heavy baskets are lowered rather than lifted, and filtration and oil separation sized for the contamination. If you are replacing an MSX 500, or matching an existing footprint, the platform is built to your dimensions.
Tank, platform and interceptor

Series photography and renders — model-specific imagery to be added.

The production tank
Engineered to site — POA

Quoted as a working system: machine, services check, chemistry, baskets, commissioning and first recipes — one number, ex GST.

Every EVS 600 ships with
  • ✓ Elevator platform (agitation optional)
  • ✓ Weir bath defence per model
  • ✓ PLC/HMI · programmable logged cycles
  • ✓ Remote diagnostics gateway
  • ✓ Insulated SS316 tank
  • ✓ AS3100 · 12-month warranty · site commissioning
415 V 3-phase · 21 kW heating · connected load TBC
Why this machine

Sized and built for heavy contamination

Six hundred litres, 1200 × 800 mm of opening and 550 mm of working depth — the EVS 600 is where batch cleaning becomes production cleaning. Seven generators hold 10,500 watts of 25 kHz across the tank, the lid is automated and double-skinned, and bath defence steps up to bag filtration (180 × 810 mm) behind the weir and interceptor.

The platform handles loads no crew should, with agitation optional for even results on dense baskets. Siemens PLC, logged recipes, remote diagnostics — 21 kW of heating, 415 V three-phase.

EvoSonic elevator platform
The feature operators talk about

The elevator platform changes how this machine gets loaded

In most factories, lifting a heavy basket into a tank means booking the overhead crane — the most fought-over asset in the building. The EVS platform ends that: parts go on by trolley, forklift or hand at deck height, the platform lowers them into the bath, and the crane goes back to jobs only a crane can do.

It cleans better — with agitation the platform works the load through the field — and it manages parts better: raise to drain, let drag-out run back, unload on the operator's schedule, not the hoist's.

Ask any operator who has run one: the platform is the feature they will not give back.

Applications

What the 600 is bought for

Engine & driveline rebuilders

Blocks, heads and housings at truck scale — the documented one-immersion strip.

Mining & heavy plant

Final drives, cylinders, undercarriage and GET — wash-bay soils at wash-bay scale.

Heat exchangers & cores

Whole-core immersion for bundles and radiators — see the case study.

Energy & power generation

Turbine hardware, filters and exchangers — the sector page covers the duty.

Machine attributes

The attribute set, from the Misonics library

Elevator platform — no liftingElevator platform — no lifting
Stepless power 10–100%Stepless power 10–100%
SweepSweep
DegasDegas
Heating to 80 °CHeating to 80 °C
Level sensingLevel sensing
Displacement weir + oil captureDisplacement weir + oil capture
Ball-valve drainsBall-valve drains
PLC touchscreen recipesPLC touchscreen recipes
Interlocks & alarmsInterlocks & alarms
Service access + remote diagnosticsService access + remote diagnostics
Programmed cyclesProgrammed cycles
Where the EVS 600 sits in the process

Ultrasonics and oscillation covered — the next stages are rinse and dry

Misonics cleaning process stages

The EVS 600 delivers the ultrasonics and oscillation stages. We quote the matching rinse tank and drying stage alongside the machine — see the multistage guide.

Chemistry

Approved chemistry

Chemistry rule: these tanks are approved for the declared chemistry at the declared concentration and temperature. Acid chemistry needs an acid-duty specification. Hydrofluoric acid, hydrochloric acid and pickling solutions are not permitted in the tank; acid processes are only possible by indirect cleaning in a chemically inert secondary container, and only with written Misonics approval.
General degrease

FX Degreaser

The daily bath for oils, grease and workshop soils — 5% in water, works from warm.

Product, SDS & TDS →Ferrous carbon & paint

FerroCarb

The heavy-hitter for baked carbon on steel and iron — the chemistry the 1.5 mm SS316 tank was built to hold.

Product, SDS & TDS →Precision & approvals

Brulin AquaVantage 815 GD

Aerospace-approved aqueous for new-manufacture and precision work; 815 QR-NF for MRO carbon.

Product, SDS & TDS →
Specification

Full specification — EVS 600

CAPACITY & DIMENSIONS
Tank Volume Capacity600 L
Tank – Length1200 mm
Tank – Width800 mm
Tank – Internal Depth650 mm
Tank – Working Depth550 mm
Overall Unit – LengthTBC mm
Overall Unit – WidthTBC mm
Overall Unit – HeightTBC mm
Machine Weight (Dry)TBC kg
Tank MaterialSS316 – 3mm
ULTRASONIC SYSTEM
Ultrasonic Power10500 W
Ultrasonic Power Density≈17.5 W/L
Ultrasonic Frequency25 kHz
Multi-FrequencyNo
Number of Generators7
Number of ResonatorsTBC
Generator Series1500 W (series TBC)
Resonator TypeTBC
Resonator MaterialSS316
Power Adjustable10–100%
HEATING SYSTEM
Heating Power21 kW
Heating Element TypeTBC
Heating Voltage415V AC 3-Ph
Temperature RangeAmbient–80 °C
Heat-Up Time 20→60 °CTBC min
Safety ThermostatTBC
Insulated TankYes (type TBC)
FILTRATION & OIL MANAGEMENT
Displacement WeirYes
Oil Capture & RemovalYes — via overflow weir
Auto-FillTBC
Filter Type#2 bag 180×810 mm
Filter SizeTBC
Filter Stage 1TBC
Filter Stage 2TBC µm
Main Tank DrainTBC
Water Supply ConnectionTBC BSP
Weir DrainTBC
CONTROL & SAFETY
Control Panel TypeSiemens S7 PLC/HMI (model TBC)
Programmable CyclesYes
Stored RecipesTBC
Level SensorsTBC
Lid TypeAutomated — double-skinned
Remote AccessYes – eWON Cosy
ELECTRICAL & POWER
Power Supply415V / 50Hz / 3-Phase
Wiring Requirements3P+E+N
IP Protection ClassTBC
POWER DRAW
Max Power ConsumptionTBC W
Total Amps DrawTBC
COMPLIANCE & WARRANTY
Machine Warranty12 months
Electrical CertificationAS3100
Machine NoiseTBC dB

Items marked TBC are being confirmed for publication.

Questions

Before you specify

What does 'heavy industrial' actually buy over the MSX floor range?
Scale and system engineering: multi-generator arrays, PLC/HMI control with logged programmable cycles, remote diagnostics, an elevator platform rated for loads no operator should touch, and factory oil management sized for genuinely dirty duty. An EvoSonic is a small plant, not a bigger tank.
What is the agitating platform option?
The load platform can oscillate through the cycle — the powered version of the oscillation stage in our process diagram. Heavy baskets clean evenly and blind holes flush instead of trapping soil.
How does the oil management work?
Continuously: the displacement weir takes the surface film, oil capture removes it from circulation, the interceptor catches solids, and stainless filtration polishes the bath — so the solution keeps working for weeks, not days.
What is the remote access for?
An industrial remote-access gateway lets our engineers read the PLC, diagnose faults and adjust parameters over the air — most support calls end without a site visit.
What power and services do these need?
415 V three-phase throughout; connected load runs from ~12 kW at the small end to 136 kW on the EVS 7000. Every quote includes a site-services check before anything ships.
Can they be customised?
Yes — the seven standard sizes cover most duties, and the same engineering delivers custom tanks, platforms and integration when they do not. The TM-series custom builds in our archive are this capability at work.
How do we prove it before committing?
Laboratory trial on your parts first; for production-scale proof we arrange project rentals and staged commissioning. No EvoSonic is bought off a brochure.
What comes with them?
Platform, lid, filtration and weir plumbing per model, PLC/HMI with recipes, level sensing, site commissioning with chemistry matched and first recipes loaded — AS3100, 12-month warranty.
